Revolutionary Instrument Propels Astronomical Imaging to New Extremes

January 6, 2012





Figure 1. Gemini South’s first light image from GeMS/GSAOI shows extreme detail in the central part of the globular star cluster NGC 288. North is up, East is right. For more technical details on this image and others see the technical companion article here.

High Resolution PNG | In Black & White

Figure 2. Gemini South laser guide star system propagating as the Milky Way rises.

High Resolution JPG

Figure 3. The Gemini South laser guide star “constellation” (upper left) is captured in this image by the lead of Gemini’s Optical Systems Group Maxime Boccas and Adaptive Optics Scientist Benoit Neichel. The image shows the 50-watt laser beam as it shines upward toward the atmospheric sodium layer about 90 kilometers above the earth’s surface to create a pattern of five artificial guide stars used to sample atmospheric turbulence for the Gemini Observatory’s GeMS adaptive optics system. The yellow-orange beam visible from lower right to upper left is caused by scattering of the laser's light by the Earth's lower atmosphere. The 30-second exposure was obtained on the night of January 21-22, 2011 and used a 500mm f/5.6 Celestron telescope with a Canon Rebel XT camera at an ISO setting of 1600. Image Credit: Gemini Observatory/AURA

High Resolution JPG

Gemini Observatory Press Release

For immediate release on January 5, 2012

Science Contacts:

  • François Rigaut
    Gemini Adaptive Optics Senior Scientist
    Gemini Observatory, La Serena, Chile
    Phone: +56-51-205 784
    frigaut"at"gemini.edu

  • Benoit Neichel
    Adaptive Optics Scientist
    Gemini Observatory, La Serena, Chile
    Phone: +56-51-205 642
    bneichel"at"gemini.edu

Media Contacts:

  • Peter Michaud
    Public Information and Outreach Manager
    Gemini Observatory, Hilo, Hawai'i
    Phone: (808) 974-2510
    Cell: (808) 936-6643
    pmichaud"at"gemini.edu

  • Antonieta Garcia
    Media Specialist
    Gemini Observatory, La Serena, Chile
    Phone: +56-51-205 628
    agarcia"at"gemini.edu

Gemini’s next-generation adaptive optics system produces highest-resolution with largest field-of-view ever captured from the ground using laser guide star technology.

For images and additional technical background information, see: www.gemini.edu/node/11718.

On December 16, 2011, a decade of hard work culminated at the Gemini South telescope in Chile, when a next-generation adaptive optics (AO) system produced its first ultra-sharp wide field image. The first target image showed a portion of a dense cluster of stars called NGC 288. This first light image reveals details at nearly the theoretical limit of Gemini’s large 8-meter mirror over an unprecedented large patch of the night sky.

The crispness of the first-light image clearly demonstrates the potential of the system, which is poised to provide astronomers with a powerful new tool for the study of a wide range of phenomena: from black holes at the centers of galaxies to the life histories of stars.

Called the Gemini Multi-conjugate adaptive optics System (GeMS for short), it uses five artificial guide stars made by a laser to provide extreme clarity over the largest area of night sky ever captured in a single AO observation — an area of the night sky which is 10 times larger than that covered by any other existing AO system in the world.

The reaction to this achievement has been swift and positive. When Space Telescope Science Institute director Matt Mountain saw the first light image, he praised the GeMS instrument team: “Incredible! You have truly revolutionized ground-based astronomy!”

Mountain was the director of the Gemini Observatory when the GeMS project began a decade ago. He also put together the original team, selecting François Rigaut as the lead scientist to develop the GeMS instrument.

Rigaut was in the Observatory’s control room high in the Chilean Andes when the new infrared image first appeared on the viewing monitor.

“We couldn’t believe our eyes!” Rigaut recalls. “The image of NGC 288 revealed thousands of pinpoint stars. Its resolution is Hubble-quality – and from the ground this is phenomenal.”

Rigaut explained that with the new gain in angular resolution the crowded city of stars captured in the first light image appears no more densely populated than a typical field in the Milky Way. “This is somewhat uncharted territory: no one has ever made images so large with such a high angular resolution.”

University of Toronto astronomer Roberto Abraham, one of a community of hundreds of astronomers worldwide who uses the 8-meter Gemini telescopes for cutting-edge research, was less reserved:

“This is fan-freaking-tastic!!!!!!!” he wrote.

The first light observing run culminated a decade-long effort in instrument planning and development. “We were lucky to have clear weather and stable atmospheric conditions that night,” said Gemini AO scientist Benoit Neichel. “Even despite interruptions of the laser propagation due to satellites and planes passing by, we obtained our first image with the system. It was surprisingly crisp and large, with an exquisitely uniform image quality.”

Gemini’s new system overcomes two limitations that have plagued the previous generation of AO systems: (1) a limited number of stars bright enough to guide on; and (2) a small field-of-view (the size of the patch of sky observed in a single observation).

While not a new solution, lasers have proved to be an effective solution to the first problem. When no "natural" guide star is available, an artificial one is created using a powerful laser emitting the well-known orange color used in some streetlights. This laser guide star technology is currently being used by observatories around the world, including both Gemini telescopes in Chile and Hawai‘i.

Gemini solved the field-of-view problem with a technique called Multi-Conjugate Adaptive Optics (MCAO). By using five laser guide stars (rather than a single one as in other systems), tomographic atmospheric modeling techniques borrowed from medical imaging, and several deformable mirrors, MCAO extends the field-of-view of AO systems by 10 times or more; it also produces images with exquisitely uniform image quality across the entire field-of-view. The Gemini Multi-Conjugate Adaptive Optics System (GeMS) is the first of its kind to combine laser guide stars with MCAO, which opens up more of the nighttime sky for detailed study.

“MCAO is game-changing,” Abraham said. "It’s going to propel Gemini to the next echelon of discovery space as well as lay a foundation for the next generation of extremely large telescopes. Gemini is going to be delivering amazing science while paving the way for the future.”

GeMS development started at Gemini in the early 2000s. The system was assembled in the Gemini instrumentation laboratories over the past four years and uses an infrared imager called the Gemini South AO Imager (GSAOI) built at the Australian National University. The GeMS team field-tested it on the telescope during several commissioning periods in 2011, and performed the final tests in mid-December.

GeMS work will continue through the first half of 2012. Testing will focus on stability, performance optimization, and integration into operations. It will gradually be opened to the Gemini astronomy community during 2012.
