Altair

Gemini NorthAO system
Last Modified:
Tuesday, March 21, 2023 - 14:51

ALTAIR (ALTtitude conjugate Adaptive optics for the InfraRed) is the facility natural/laser guide star adaptive optics system of the Gemini North telescope. It can feed a corrected beam to Gemini instruments NIRI and NIFS. Deploying ALTAIR is "transparent" for the science instrument, as it reproduces the telescope focal ratio (f/16), pupil size and pupil position. ALTAIR is usable in the 1 - 2.5 micron range, with best results achieved in the H and K bands. L- and M-band performance is poor because of the low (~15%) transmittance of the ALTAIR optics in those bands and the greatly increased thermal background.

Available For Proposals at Gemini North
For more details, see the schedules and the CfPs.

Altair is currently available in Natural Guide Star and LGS+ P1 modes.

LGS+TTGS availability will be confirmed shortly after the post shutdown engineering nights (new SFO camera!)

×

Current Instruments

  • Altair
    • Modes
    • Performance
    • Field Lens
    • Observation Preparation
    • Documents
  • GHOST
  • IGRINS
  • NIRI
  • GNIRS
  • NIFS
  • GMOS
  • GeMS
  • Flamingos 2
  • GSAOI
  • `Alopeke & Zorro
  • GRACES
  • MAROON-X

Capability Summary

Natural Guide Star (NGS)

  • Guide star magnitude limit
    • 11-12 mag for full correction
    • 15-16 mag for partial correction
  • Core FWHM~0.08"

Laser guide Star (LGS)

  • High Strehl correction limits
    • Guide star magnitude: 8.5 < R < 15
    • Guide star within 15"
    • 50% of NGS Strehl
  • Low Strehl correction
    • Guide star magnitude: 15 < R < 17.5-18.5 (depends on SB)
    • Guide star within 25"
    • Strehl of ~10%

Super Seeing (LGS+P1)

  • Improves IQ by a factor of 2-3 over the natural seeing (on-axis)
  • P1WFS magnitude limit: R ~ 14

ALTAIR was built by the Herzberg Institute of Astrophysics (HIA), Canada. ALTAIR Natural Guide Star (NGS) function has been offered since 2004A. In 2007A, the ALTAIR Laser Guide Star (LGS) commissioning was completed.

Announcements

May 19, 2022

Altair unavailable

January 15, 2021

Altair Available!

View All Altair News

Instrument Team

gn Instrument Scientist

Christophe Clergeon

gn Additional Support Staff
    • Andy Stephens
    • Garima Singh

Email: christophe.clergeon@noirlab.edu
